性能参数：
尺寸 | 1＂ |
流量 | 14 GPM(52 LPM) |
含固粒径 | 0.15＂(4 mm) |
扬程 | 100 PSI(6.9 BAR) |
每冲程排量 | 0.026 gal(0.098 L) |
常用型号：
S10B1K1KPAS000. S10B1K2KPAS000. S10B1KZKPAS000. S10B1N1NPAS000.
S10B1N2NPAS000. S10B1NZNPAS000. S10B1P1PPAS000. S10B1P2PPAS000.
S10B1PZPPAS000.
Material:
Wetted Material：Polypropylene、Nylon、PVDF
Non-Wetted Material：Polypropylene
Diaphragm Materials：EPDM、FKM、Hytrel、Neoprene、BUNA、Santoprene、PTFE
Performance:
SIZE | 1＂ |
CAPACITY | 14 GPM(52 LPM) |
SOLIDS-HANDLING | 0.15＂(4 mm) |
MAXIMUM OPERATING PRESSURE | 100 PSI(6.9 BAR) |
DISPLACEMENT/STROKE | 0.026 gal(0.098 L) |
Models:
S10B1K1KPAS000. S10B1K2KPAS000. S10B1KZKPAS000. S10B1N1NPAS000.
S10B1N2NPAS000. S10B1NZNPAS000. S10B1P1PPAS000. S10B1P2PPAS000.
S10B1PZPPAS000.
<
<
<
<
