性能参数：
尺寸 | 1＂ |
流量 | 53 GPM(200 LPM) |
含固粒径 | 0.25＂(6 mm) |
扬程 | 100 PSI(6.9 BAR) |
每冲程排量 | 0.19 gal(0.72 L) |
常用型号：
S1FB3C1PCUS000. S1FB3C2PCUS000. S1FB3CBPCUS000. S1FB3CGPCUS000.
S1FB3CNPCUS000. S1FB3CVPCUS000. S1FB3CZPCUS000. S1FB3K1KPUS000.
S1FB3K2KPUS000. S1FB3KGKPUS000. S1FB3KVKPUS000. S1FB3KZKPUS000.
S1FB3P1PPNI000. S1FB3P1PPUS000. S1FB3P2PPNI000. S1FB3P2PPUS000.
S1FB3PBPPNI000. S1FB3PBPPUS000. S1FB3PGPPNI000. S1FB3PGPPUS000.
S1FB3PMPPUS000. S1FB3PNPPNI000. S1FB3PNPPUS000. S1FB3PVPPNI000.
S1FB3PVPPUS000. S1FB3PZPPNI000. S1FB3PZPPUS000. S1FB3V1KCUS000.
S1FB3V2KCUS000. S1FB3VGKCUS000. S1FB3VVKCUS000. S1FB3VZKCUS000.
Material:
Wetted Material：Polypropylene / Conductive Polypropylene、PVDF / Conductive PVDF
Non-Wetted Material：Polypropylene、 40% Glass Filled、Polypropylene、Conductive Polypropylene
Diaphragm Materials：EPDM、FKM、Hytrel、Neoprene、BUNA、Santoprene、PTFE
Performance:
SIZE | 1＂ |
CAPACITY | 53 GPM(200 LPM) |
SOLIDS-HANDLING | 0.25＂(6 mm) |
MAXIMUM OPERATING PRESSURE | 100 PSI(6.9 BAR) |
DISPLACEMENT/STROKE | 0.19 gal(0.72 L) |
Models:
S1FB3C1PCUS000. S1FB3C2PCUS000. S1FB3CBPCUS000. S1FB3CGPCUS000.
S1FB3CNPCUS000. S1FB3CVPCUS000. S1FB3CZPCUS000. S1FB3K1KPUS000.
S1FB3K2KPUS000. S1FB3KGKPUS000. S1FB3KVKPUS000. S1FB3KZKPUS000.
S1FB3P1PPNI000. S1FB3P1PPUS000. S1FB3P2PPNI000. S1FB3P2PPUS000.
S1FB3PBPPNI000. S1FB3PBPPUS000. S1FB3PGPPNI000. S1FB3PGPPUS000.
S1FB3PMPPUS000. S1FB3PNPPNI000. S1FB3PNPPUS000. S1FB3PVPPNI000.
S1FB3PVPPUS000. S1FB3PZPPNI000. S1FB3PZPPUS000. S1FB3V1KCUS000.
S1FB3V2KCUS000. S1FB3VGKCUS000. S1FB3VVKCUS000. S1FB3VZKCUS000.
<
<
<
<
